Steel Structure Support Frame

Description

The Steel Structure Support Frame is a high-strength, precision-engineered steel framework widely used in industrial construction, equipment support, modular structures, energy projects, warehouses, factories, and large-scale infrastructure.
Made from superior-grade structural steel such as Q355, Q460, S355, S460, ASTM A36, A572, the support frame provides exceptional load-bearing capacity, structural stability, and long-term durability.
The frame is designed to accommodate various applications including:
Equipment platforms
Pipe rack systems
Mechanical support structures
Industrial plant frameworks
Prefabricated building skeletons
Heavy-load operating platforms
Every Steel Structure Support Frame is modular, customizable, prefabricated, and compliant with EN, AISC, ASTM, international design standards.

Product Attributes

Trade Information

● Unit of Measurement: Ton

● Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.

● Minimum Order Quantity (MOQ): 100 Tons

Key Advantages

① High Load-Bearing Strength
Engineered to support heavy industrial equipment, pipelines, conveyors, and machinery.
Structural safety ensured under static and dynamic loads.
Excellent resistance to deformation and vibration.

② Fully Customized Design
Support frames tailored by height, span, thickness, and load requirements.
CAD/CAE/TEKLA-based structural modeling guarantees precision.
Compatible with steel grating platforms, stairs, handrails, and maintenance walkways.

③ Modular Prefabrication for Fast Installation
All components prefabricated in the factory for high accuracy.
Quick on-site assembly reduces labor and construction time.
Ideal for industrial parks, factories, and tight-schedule projects.

④ Long Service Life & Anti-Corrosion Protection
Hot-dip galvanizing, epoxy coating, or customized multiphase painting system.
Suitable for corrosive environments such as chemical plants, ports, and coastal areas.
Designed for a 30–50-year lifespan.

⑤ Superior Stability & Safety
Rigid frame, bracing, and column-beam connection ensure structural reliability.
Seismic resistance designed per local standards.
Anti-slip platforms and safety guardrails available.

Manufacturing Process & Technical Features

① Precision Fabrication
CNC laser/plasma cutting for exact dimensions.
Robotic welding and submerged arc welding (SAW).
Weld inspection includes UT, MT, RT, and VT per ISO 3834 / AWS D1.1.

② Assembly Simulation Before Shipping
All frames are pre-assembled in the factory to ensure perfect alignment.
Bolt-hole accuracy strictly controlled (≤2 mm tolerance).
Tekla-based model checks avoid installation errors.

③ Surface Treatment Excellence
Sandblasting to Sa 2.5 standard.
Coating systems from Jotun, Hempel, or International Paint.
Hot-dip galvanizing thickness: ≥85–120 µm.

④ Efficient Packaging & Transportation
Modular steel components designed for standard container shipping.
Steel racks ensure safe, compact, and cost-effective transport.

Technical Specifications

Application

Industrial equipment support
Pipe racks for oil & gas, chemical plants
Steel structure platforms for factories
Mining and energy project frameworks
Modular building skeletons
Conveyor and machinery support systems
Storage and logistics platforms

Why Choose Us

20+ years of heavy steel structure manufacturing experience
CE, EN1090, ISO 3834, ASME certified
Advanced CNC, robotic welding, and automated assembly lines
Professional engineering team for global custom projects
Competitive pricing with strict quality assurance
Exported to 20+ countries (Middle East, Europe, Africa, Asia, etc.)

Our Factory

Raw material storageMaterial cuttingAutomatic Welding

Manual weldingWeld seam treatmentDeep processing

PaintingDeliveryPackaging
