Modular Steel Truss System for Long-Span Structures
- Product Model: ASTM A36/ASTM A572GR50/EN S355JR/S355J2 Steel Structure
- Unit of Measurement: Ton
- Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.
- MOQ: 100 Tons
- Overview
- OUR FACTORY
- Recommended Products
Long-Span Capability
Optimized truss design suitable for large spans, reducing intermediate supports and maximizing usable space.Modular Design
Truss sections can be prefabricated in standardor customized modules, improving manufacturing efficiency and simplifying transportation and installation.
High Structural Performance
Designed to withstand heavy loads, wind, and seismic requirements according to project specifications.Factory Prefabrication
High-precision fabrication under controlled conditions ensures dimensional accuracy and consistent quality.Flexible Connection Options
Bolted or welded connections available to meet different site and installation requirements.
Product Overview
Our Modular Steel Truss System is designed for long-span structures requiring high load-bearing capacity, structural stability, and efficient installation. The system adopts a modular design concept, allowing flexible configuration, convenient transportation, and rapid on-site assembly. It is widely used in industrial, commercial, and public infrastructure projects.
Key Features
Technical Specifications
| After-sales Service | On site installation or installation guidance |
| Warranty Period | 1 year |
| Transportation Packaging | Container or bulk carrier transportation |
| Specification | Based on actual project products |
| Brand | Guoshun |
| Place of Origin | Jinan |
| Standard | European, American, and National Standards |
| Surface Treatment | Spray painting or galvanizing |
Technical Specifications
Material Options:
S235 / S355 / High-strength steel (or equivalent ASTM grades upon request)
Span Range:
Custom-designed according to project requirements
Truss Type:
Square truss, triangular truss, or customized configurations
Surface Treatment:
Shop primer + finish paint
Hot-dip galvanizing
Duplex coating system (for aggressive environments)
Fabrication Standards:
EN 1090, AWS D1.1, or equivalent international standards
Applications
Industrial buildings and factories
Logistics warehouses and distribution centers
Exhibition halls and convention centers
Stadiums and sports facilities
Transportation terminals and public infrastructure
Quality Control
CNC cutting and drilling for precise dimensions
Qualified welders with approved WPS/PQR
Dimensional inspection and visual welding inspection
Optional NDT (UT / MT) for critical joints
Pre-assembly inspection for key structural modules
Trade Information
● Unit of Measurement: Ton
● Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.
● Minimum Order Quantity (MOQ): 100 Tons
Packaging & Delivery
Modular packing to optimize container or break-bulk shipment
Protective measures for coated surfaces during transport
Clear identification markings for easy on-site installation
Why Choose Us
Extensive experience in engineering-oriented steel structure projects
Strong capability in customized design and fabrication
Stable production capacity for medium to large-scale projects
Professional technical support from design to delivery
