Wall Cladding System
- Product Model: ASTM A36/ASTM A572GR50/EN S355JR/S355J2 Steel Structure
- Unit of Measurement: Ton
- Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.
- MOQ: 100 Tons
- Overview
- OUR FACTORY
- Recommended Products
Product Overview
The Wall Cladding System is an external or internal enclosure system designed to provide protection, insulation, weather resistance, and architectural appearance for steel structures and buildings. It consists of cladding panels, supporting members, fasteners, and sealing components, forming a durable and efficient building envelope.
Wall cladding systems are widely used in:
Steel structure industrial buildings
Warehouses and logistics centers
Commercial and office buildings
Power plants and industrial facilities
Modular and prefabricated buildings
Agricultural and utility buildings
Key Advantages
Excellent Weather Protection
Effectively resists wind, rain, dust, and UV exposure.
Thermal & Acoustic Insulation
Improves indoor comfort and energy efficiency.
Lightweight & High Strength
Reduces structural load while maintaining durability.
Fast Installation
Prefabricated panels enable rapid construction.
Modern & Clean Appearance
Enhances architectural aesthetics.
Low Maintenance
Long service life with minimal upkeep.
Flexible System Design
Suitable for various building types and layouts.
Product Attributes
| After-sales Service | On site installation or installation guidance |
| Warranty Period | 1 year |
| Transportation Packaging | Container or bulk carrier transportation |
| Specification | Based on actual project products |
| Brand | Guoshun |
| Place of Origin | Jinan |
| Standard | European, American, and National Standards |
| Surface Treatment | Spray painting or galvanizing |
Technical Features & Production Process
Technical Features
Cladding materials: steel sheet, sandwich panel, aluminum panel
Panel types: single-layer sheet or insulated sandwich panelInsulation core options: EPS, PU, PIR, Rock Wool
Horizontal or vertical installation
Compatible with steel frame structuresHigh wind resistance and fire-rated options available
Designed according to international building envelope standards
Production Process
Wall cladding system design and detailing
Panel profile forming and cutting
Insulation core bonding (for sandwich panels)
Surface coating and curing
Quality inspection and packagingTransportation and on-site installation
Technical Specifications (Customizable)
| Item | Specification Range |
| Product Type | Wall Cladding System |
| Panel Type | Single Sheet / Sandwich Panel |
| Panel Thickness | 0.4 – 0.8 mm (steel sheet) |
| Insulation Thickness | 50 – 200 mm |
| Insulation Material | EPS / PU / PIR / Rock Wool |
| Installation Method | Horizontal / Vertical |
| Surface Coating | PE / SMP / HDP / PVDF |
| Fire Rating | Up to A1 (Rock Wool) |
| Design Standard | GB / EN / ASTM / AS |
| Design Life | 20 – 30 years |
Application Scenarios
Industrial Workshops & Warehouses
Commercial & Office Buildings
Power Plants & Industrial Facilities
Prefabricated & Modular Buildings
Agricultural & Utility Structures
Steel Structure Enclosure Systems
Trade Information
● Unit of Measurement: Ton
● Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.
● Minimum Order Quantity (MOQ): 100 Tons
Why Choose Us
Professional Wall Cladding System Supplier
Extensive experience in steel building envelope solutions.
Advanced Production Lines
Roll forming, continuous sandwich panel production, and precision cutting.
Strict Quality Control System
Raw material inspection, panel testing, and coating quality control.
Customized System Solutions
Optimized for thermal performance, fire safety, and aesthetics.
Global Project Experience
Wall cladding systems supplied to projects worldwide.
Reliable Delivery & Competitive Pricing
Factory-direct manufacturing ensures stable quality and timely supply.
