Braced Frame Structure
- Product Model: ASTM A36/ASTM A572GR50/EN S355JR/S355J2 Steel Structure
- Unit of Measurement: Ton
- Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.
- Overview
- Recommended Products
Product Overview
The Braced Frame Structure is a steel structural system that uses diagonal or cross bracing members to enhance the stability and lateral load resistance of a building or framework. By efficiently transferring wind, seismic, and horizontal loads to the foundation, braced frame structures significantly improve the overall strength, stiffness, and safety of steel buildings.
Braced frame structures are widely used in:
Industrial steel buildings and workshops
Warehouses and logistics centers
High-rise and mid-rise buildings
Power plants and industrial facilities
Pipe racks and equipment support systems
Common bracing types include:
Diagonal Bracing
Cross (X) Bracing
V-Bracing and Inverted V-Bracing
K-Bracing and Eccentric Bracing
Product Attributes
| After-sales Service | On site installation or installation guidance |
| Warranty Period | 1 year |
| Transportation Packaging | Container or bulk carrier transportation |
| Specification | Based on actual project products |
| Brand | Guoshun |
| Place of Origin | Jinan |
| Standard | European, American, and National Standards |
| Surface Treatment | Spray painting or galvanizing |
Trade Information
● Unit of Measurement: Ton
● Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.
● Minimum Order Quantity (MOQ): 100 Tons
Key Advantages
Excellent Lateral Load Resistance
Effectively resists wind and seismic forces.
High Structural Stability
Reduces lateral displacement and building drift.
Efficient Load Transfer
Channels forces safely to foundations.
Cost-Effective Structural System
Optimized steel usage lowers overall construction cost.
Flexible Design Options
Suitable for various building heights and layouts.
Prefabricated & Fast Installation
Factory-fabricated components enable rapid erection.
Durable & Long Service Life
Designed for long-term structural performance.
Technical Features & Production Process
1 Technical Features
High-strength structural steel: Q235B / Q355B / Q420 or equivalent
Various bracing configurations to suit architectural needs
Bolted or welded connections
High stiffness-to-weight ratio
Compatible with steel beams, columns, and floor systems
Fireproof and corrosion protection systems available
Designed according to international building codes
2 Production Process
Structural analysis and braced frame design
Shop drawing preparation and approval
Steel cutting, drilling, and fabrication
Assembly and welding or bolting
Non-destructive testing (if required)
Dimensional inspection and trial assembly
Surface treatment (sandblasting, painting, galvanizing)
Packing, transportation, and site installation
Technical Specifications (Customizable)
| Item | Specification Range |
| Structure Type | Braced Frame Structure |
| Bracing Type | Diagonal / X / V / K |
| Building Height | Low-rise to High-rise |
| Span Length | Customized |
| Steel Grade | Q235B / Q355B / Q420 |
| Connection Type | Bolted / Welded |
| Surface Treatment | Painted / Galvanized |
| Fire Protection | Fireproof coating (optional) |
| Design Standard | GB / EN / ASTM / AS |
| Design Life | 30 – 50 years |
Application Scenarios
Industrial Workshops & Warehouses
Commercial & Office Buildings
Power Plants & Industrial Facilities
Pipe Racks & Equipment Support Structures
Seismic-Resistant Buildings
Why Choose Us
Professional Steel Structure Manufacturer
Extensive experience in braced frame design and fabrication.
Advanced Fabrication Equipment
CNC cutting, automatic welding, and precision assembly.
Strict Quality Control System
Material traceability, welding inspection, and dimensional checks.
Customized Engineering Solutions
Structural optimization for safety, stiffness, and cost efficiency.
Global Project Experience
Braced frame structures supplied to projects worldwide.
Reliable Delivery & Competitive Pricing
Factory-direct manufacturing ensures consistent quality and on-time delivery.
Our Factory
Raw material storageMaterial cuttingAutomatic Welding
Manual weldingWeld seam treatmentDeep processing
PaintingDeliveryPackaging
