Assembled steel bridge

Description

The Assembled Steel Bridge is a modular, prefabricated, and rapidly deployable bridge system widely used for highways, municipal roads, pedestrian crossings, emergency reconstruction, mining access roads, military transport routes, and temporary or permanent river crossings.

All components—including main girders, trusses, decks, bracings, and connectors—are fully prefabricated in the factory, enabling fast assembly, high structural stability, and excellent load-bearing capacity.

With superior durability and easy installation, assembled steel bridges offer an efficient, cost-effective solution for modern transportation infrastructure.


Product Attributes

Trade Information

● Unit of Measurement: Ton

● Price Range: 1300—3000 USD/T.The specific price needs to be provided with drawings and calculated based on material requirements, processing requirements, paint requirements, etc.

● Minimum Order Quantity (MOQ): 100 Tons

Key Advantages

① Fast Installation – 50–70% Faster than Concrete Bridges
All components are modular and standardized.
No need for heavy construction equipment.
Ideal for urgent projects or remote areas.

② High Load-Bearing Capacity
Designed for heavy trucks, military vehicles, and multiple traffic lanes.
Suitable for long-span applications.
Excellent bending and fatigue resistance.

③ Long Service Life & Corrosion Protection
Hot-dip galvanizing / epoxy zinc-rich coating available.
Designed for 30–50+ years of service life.
Suitable for coastal, desert, high-humidity, and high-temperature regions.

④ Easy Maintenance & Low Lifecycle Cost
Modular components allow easy replacement.
Simple maintenance routine.
Lower overall cost compared with concrete structures.

⑤ Flexible, Scalable & Reusable
Span length can be extended by adding panels.
Can be dismantled, transported, and reused.
Ideal for temporary or semi-permanent projects.

Technical Features

① Modular Components
Prefabricated truss panels
Steel girders (H-beam, box girder, truss girder)
Cross bracings & connection plates
Anti-slip steel deck
Guardrails & side panels

② High-Precision Fabrication
CNC cutting, automatic drilling
Robot welding for uniform strength
TEKLA 3D modeling ensures installation accuracy

③ Surface Treatment Options
Hot-dip galvanizing (HDG) for maximum corrosion resistance
Multi-layer industrial paint
Powder coating available on request

④ Connection System
Bolted connections (international-standard high-strength bolts)
No on-site welding required
Fast and safe assembly

Technical Specifications

Application

Highway bridges
rban road bridges
Rural transportation
Emergency rescue bridges
Military bridges
Mining and industrial access routes
River/valley crossings
Temporary or permanent bridge replacement

Why Choose Us

20+ years experience in steel bridge fabricaMunicipal & ution
CE, EN 1090, ISO 3834 welding certification
Large-scale production capacity
Projects delivered in 20+ countries
Full design support (2D/3D models, structural calculations)
On-site installation guidance & after-sales service
